Conventional Busbar Straight Length

Name: Conventional Busbar Straight Length
Brand: Ganpati Electricals Pvt. Ltd.
Price: 3148-3523 INR
Availability: InStock

Price 3148-3523 INR/ Kilograms

Get a Price/Quote

MOQ : 500 Kilograms

Conventional Busbar Straight Length Specification

Connector Type
Copper/Aluminium Lugs

Humidity %
Up to 95% RH

IP Rating
IP55

Surface Finish
Tinned / Bare / Polished

Shape
Rectangular

Power Factor
0.95

Overheating Protection
YES

Mounting Type
Surface Mounted

Operating Temperature
-30°C to 85°C

Efficiency
98%

Insulation Material
Rigid PVC / Epoxy Coated

Feature
High conductivity, Corrosion resistance

Product Type
Busbar Straight Length

Application
Electrical Distribution

Protection Level
IP55

Frequency (MHz)
50 Hz

Rated Voltage
660 V AC

Energy Consumption
Low

Output Type
Straight Conductor

Color
Copper/Aluminium Bare

Dimension (L*W*H)
3000 mm x 50 mm x 10 mm

Weight
5 kg per meter

Size
Standard/Custom

Input Voltage
660 V

Phase
Three Phase

Material
Copper / Aluminium

Connection Type
Bolted Joint

No Of Poles
3

Compliance Standard
IEC 61439-1/2

Corrosion Protection
Available with coated option

Conductor Type
Solid Bar

Current Carrying Capacity
800A - 4000A

Fire Resistance
Yes

Ambient Temperature Range
-30°C to 50°C

Mechanical Strength
High

Conventional Busbar Straight Length Trade Information

Minimum Order Quantity
500 Kilograms

Supply Ability
15000 Kilograms Per Month

Delivery Time
1 Months

About Conventional Busbar Straight Length

Ganpati Electricals Pvt. Ltd. is a business partner of Larsen & Toubro for Bus Bar Trunking System, which is used in hotels, data centers, hospitals, airports, industries, factories, apartments etc. Electrical busbar systems are a modular approach to electrical wiring.

Busbar Trunking System is a prefabricated electrical distribution system consisting of busbars in a protective enclosure, including straight lengths, fittings, devices and accessories. These are mainly of two types namely Air-Insulated Trunking Busbar System and Sandwich Trunking Busbar System.

Sandwich Busbar Trunking System is epoxy insulated and used for transferring 400A to 6300A current for up to a maximum of 1000V. Compaired to this Conventional Busbar Trunking System is air insulated and is used for 100-400A current for upto a maximum of 415V. Besides these two, there comes also air-insulated Medium Voltage Busbar Trunking System for 100A to 6300A current for up to a maximum load of 33 kV.

Busbar Trunking System of L&T comes in a metal enclosure and is quite compact in size. It requires no maintenance and can easily last for more than 20 years. Compared to normal cabling, it requires much less space and can be installed within a very short time.

Sandwich Busbar Trunking System has a high tolerance to heavy voltage drop. It has single bolted copper or alumium busbars meant for 400A to 6300A current for a load of maximum 1000V.

Compared to Sandwich Busbar Trunking System, Conventional Busbar Trunking System is air-insulated. It has multi-bolted copper busbars housed in a 1.6 mm thick GI container having epoxy coating. Conventional Busbar Trunking System is meant for 100A to 400A current for an operating voltage upto 415V.

Larsen & Toubro has also Medium Voltage Busbar Trunking System for 400A to 5000A current for a load of 3.6 kV to 24kV. The enclosure is made of GI, Stainless Steel or Aluminium and is epoxy coated. The Busbars are made of Copper or Aluminium having multiple bolted splice plate joints.

All types of L&T Busbar Trunking Systems are ISO approved for their quality and for fire safety.

Reliable Electrical Performance

Engineered with solid copper or aluminium, this busbar delivers consistent performance even under high loads up to 4000A. Its compliance with IEC 61439-1/2 and robust fire resistance ensure safety and adherence to international standards, making it a trusted choice for critical power infrastructure.

Customizable and Durable Design

The busbar is available in standard as well as customizable dimensions to suit varied applications. With high mechanical strength, IP55 protection, and corrosion-protected options, it withstands harsh operating environments, while its surface finish options offer additional resistance and versatility.

Simple Installation & Low Maintenance

Supplied with bolted joints and compatible copper or aluminium lugs, the busbar is surface-mounted for ease of installation. The rigid PVC or epoxy insulation increases safety while minimizing maintenance, and its 98% efficiency ensures minimal energy loss during operation.

FAQs of Conventional Busbar Straight Length:

Q: How do I install the conventional busbar straight length for electrical distribution systems?

A: Installation involves securely surface mounting the busbar with bolted joints and connecting the conductors using copper or aluminium lugs. Ensure rigid PVC or epoxy coated insulation is in place and always follow IEC 61439-1/2 and local safety protocols for maximum protection and performance.

Q: What are the main benefits of using this solid bar busbar in an industrial setup?

A: The busbar offers high conductivity, robust mechanical strength, excellent fire and corrosion resistance, and minimal energy loss (98% efficiency), making it ideal for demanding industrial environments. Its customizability and IP55 protection enhance versatility and safety in electrical distribution.

Q: When is it recommended to use the coated corrosion-protected variant?

A: Choose the corrosion-protected coated variant if the busbar will be exposed to environments with high humidity or corrosive agents, such as coastal regions or chemical plants. This ensures long-term reliability and prevents degradation over time.

Q: Where can these busbars be used and who supplies them in India?

A: These busbars are suitable for electrical distribution in commercial, industrial, and utility networks and are available through distributors, suppliers, traders, and wholesalers across India. Their adaptable design makes them appropriate for both new installations and upgrades.

Q: What is the process for ordering a custom-sized busbar?

A: To order a custom-sized busbar, specify your required dimensions, material (copper or aluminium), and surface finish to your distributor or supplier. They will confirm compliance with standards, provide a quotation, and fabricate the product to match your installation requirements.

Q: How does the busbar ensure operational safety and overheating protection?

A: Designed for robust performance, the busbar includes overheating protection features, rigid insulation, and adherence to IEC 61439-1/2. Its fire-resistant construction and IP55 ingress protection further safeguard users and equipment during operation.

Q: What usage environments are supported by the busbars design specifications?

A: The busbar operates efficiently in ambient temperatures from -30C to 85C, withstanding up to 95% relative humidity. Its high mechanical strength, corrosion resistance, and adaptable mounting support demanding indoor and covered outdoor environments.
