Sandwich Busbar Flatwise Offset

Name: Sandwich Busbar Flatwise Offset
Brand: Ganpati Electricals Pvt. Ltd.
Price: 3148-3523 INR
Availability: InStock

Price 3148-3523 INR/ Kilograms

Get a Price/Quote

MOQ : 500 Kilograms, ,

Sandwich Busbar Flatwise Offset Specification

Shape
Flatwise Offset

Humidity %
Up to 95% Non-condensing

Overheating Protection
YES

Efficiency
Over 98%

Surface Finish
Smooth Insulated Finish

Connector Type
Standard Clamp or Bolt-on Terminals

Power Factor
>0.95

Insulation Material
Epoxy Powder Coated or Halogen-Free Insulation

Feature
High Current Carrying Capacity, Compact Design, Flame Retardant Insulation

IP Rating
IP55

Mounting Type
Horizontal/Vertical Mounting

Operating Temperature
-20C to +80C

Product Type
Sandwich Busbar

Application
Power Distribution, Switchgear Panels, Electrical Enclosures

Protection Level
High

Frequency (MHz)
50/60 Hz

Rated Voltage
690V

Energy Consumption
Low Loss Conductivity

Output Type
Direct Power Output

Color
Red (Outer Insulation)

Dimension (L*W*H)
1000 mm x 60 mm x 10 mm

Weight
4.5 kg

Phase
Three Phase

Size
Customized size available

Input Voltage
415690V

Connection Type
Bolt/Clamp Type

No Of Poles
3 or 4

Material
Copper or Aluminum with Insulated Sandwich Structure

Corrosion Protection
Anti-corrosive Coating

Flame Resistance Class
V-0, EN 60695-11-10

Mechanical Strength
High Mechanical Rigidity

Service Life
>25 Years

Creepage Distance
>25 mm

Accessories Available
Joint Covers, End Caps, Elbows, Tees, Supports

Ambient Conditions
Indoor/Outdoor Use

Short Circuit Withstand
Up to 50 kA for 1 second

Current Rating
Up to 2500A

Dielectric Strength
>20 kV/mm

Sandwich Busbar Flatwise Offset Trade Information

Minimum Order Quantity
500 Kilograms, ,

Supply Ability
15000 Kilograms, , Per Month

Delivery Time
1 Months

About Sandwich Busbar Flatwise Offset

Sandwich Busbar Flatwise Offset is a metallic strip or bar, typically housed inside switchgear, panel boards, and busway enclosures for local high current power distribution. They are also used to connect high voltage equipment at electrical switchyards, and low voltage equipment in battery banks. Busbars are solid metal bars used to carry current. Typically made from copper or aluminum, busbars are rigid and flat. The Sandwich Busbar Flatwise Offset is made available by us for use in the various places.

Robust Performance and Safety Features

This busbar guarantees reliable power distribution with exceptional current-carrying capacity and outstanding flame retardancy. The anti-corrosive coating, high mechanical rigidity, and smooth insulated finish ensure optimal protection and long service life, making it a top choice for industrial environments.

Flexible Design for Diverse Applications

Suitable for both three-phase power distribution and a wide range of installation scenarios, the Sandwich Busbar Flatwise Offset supports custom sizes and multiple mounting orientations. Accessories expand its usability in complex electrical systems while maintaining high efficiency and a power factor over 0.95.

Easy Installation and Maintenance

The bolt or clamp terminal connections permit straightforward, secure assembly. Accessories like joint covers and support brackets streamline connectivity and enhance maintenance access, while the IP55 rating and flame-retardant insulation provide additional assurance in both indoor and outdoor environments.

FAQs of Sandwich Busbar Flatwise Offset:

Q: How do I install the Sandwich Busbar Flatwise Offset in my power distribution system?

A: Installation involves securing the busbar with either bolt or clamp-type terminals and using available accessories such as supports, elbows, or end caps as required. The busbar can be mounted horizontally or vertically, making it suitable for diverse layouts in switchgear panels or electrical enclosures.

Q: What are the primary benefits of using a sandwich busbar with high flame resistance and dielectric strength?

A: The V-0 flame resistance class and dielectric strength over 20 kV/mm significantly enhance operational safety, minimizing electrical fire risks and preventing insulation breakdowns, especially in environments that demand high reliability and protection.

Q: When should I choose a flatwise offset busbar over traditional round busbars?

A: Flatwise offset busbars offer a compact and space-saving design, high current carrying capacity, and easier integration in confined electrical enclosures. They are ideal for applications requiring high efficiency, minimal losses, and strong mechanical rigidity.

Q: Where can the Sandwich Busbar Flatwise Offset be used effectively?

A: It is designed for indoor and outdoor environments, commonly utilized in power distribution systems, switchgear panels, and electrical enclosures for both industrial and commercial applications across varied ambient conditions, with humidity tolerance up to 95% non-condensing.

Q: What is the expected service life and maintenance process for this busbar?

A: The busbar is engineered for a service life of over 25 years, requiring minimal maintenance due to its anti-corrosive coating and high mechanical rigidity. Periodic inspections of connections and accessories are recommended to ensure long-term performance.

Q: How does the sandwich structure and insulation material enhance protection and efficiency?

A: The sandwich construction with insulated epoxy powder or halogen-free material provides high dielectric protection, excellent flame retardancy, and low-loss conductivity, achieving over 98% efficiency. This design reduces energy loss and ensures reliable operation in high-demand settings.
