Sandwich Busbar Straight Length (Feeder Type)

Name: Sandwich Busbar Straight Length (Feeder Type)
Brand: Ganpati Electricals Pvt. Ltd.
Price: 3148-3523 INR
Availability: InStock

Price 3148-3523 INR/ Kilograms

Get a Price/Quote

MOQ : 500 Kilograms

Sandwich Busbar Straight Length (Feeder Type) Specification

Mounting Type
Ceiling/Wall/Trunking Mounted

Shape
Rectangular

Surface Finish
Powder Coated, Smooth Finish

Connector Type
Plug-in Tap Off Box/Insert Joint System

Feature
Compact Design, Pre-Fabricated, High Safety, Easy Installation

Operating Temperature
-20C to +55C

Overheating Protection
Built-in Thermal Insulation

Humidity %
Up to 95% non-condensing

Efficiency
>98%

Insulation Material
Epoxy Resin/Polyester Film

IP Rating
IP54/IP65

Power Factor
>0.95

Product Type
Feeder Type Sandwich Busbar Straight Length

Application
Industrial Power Distribution, Commercial Panel Boards

Protection Level
Insulated Enclosure, Touch-Proof

Frequency (MHz)
50/60 Hz

Rated Voltage
Up to 690V

Energy Consumption
Low (due to minimal transmission losses)

Output Type
Feeder Output

Color
Grey with Colored Phase Markings

Dimension (L*W*H)
Standard Length 3m/6m, Width and Height as per rating

Weight
Approx. 8-12 kg/m (depends on size & rating)

Phase
Three Phase

Size
100A to 5000A (custom sizes available)

Input Voltage
Up to 690V

Material
Copper or Aluminum Conductors, Steel Sheet/Aluminum Extrusion Casing

Connection Type
Bolt/Joint Clamp Connection

No Of Poles
3 or 4

Sandwich Busbar Straight Length (Feeder Type) Trade Information

Minimum Order Quantity
500 Kilograms

Supply Ability
15000 Kilograms Per Month

Delivery Time
1 Months

About Sandwich Busbar Straight Length (Feeder Type)

Ganpati Electricals Pvt. Ltd. is a business partner of Larsen & Toubro for Bus Bar Trunking System, which is used in hotels, data centers, hospitals, airports, industries, factories, apartments etc. Electrical busbar systems are a modular approach to electrical wiring.

Busbar Trunking System is a prefabricated electrical distribution system consisting of busbars in a protective enclosure, including straight lengths, fittings, devices and accessories. These are mainly of two types namely Air-Insulated Trunking Busbar System and Sandwich Trunking Busbar System.

Sandwich Busbar Trunking System is epoxy insulated and used for transferring 400A to 6300A current for up to a maximum of 1000V. Compaired to this Conventional Busbar Trunking System is air insulated and is used for 100-400A current for upto a maximum of 415V. Besides these two, there comes also air-insulated Medium Voltage Busbar Trunking System for 100A to 6300A current for up to a maximum load of 33 kV.

Busbar Trunking System of L&T comes in a metal enclosure and is quite compact in size. It requires no maintenance and can easily last for more than 20 years. Compared to normal cabling, it requires much less space and can be installed within a very short time.

Sandwich Busbar Trunking System has a high tolerance to heavy voltage drop. It has single bolted copper or alumium busbars meant for 400A to 6300A current for a load of maximum 1000V.

Compared to Sandwich Busbar Trunking System, Conventional Busbar Trunking System is air-insulated. It has multi-bolted copper busbars housed in a 1.6 mm thick GI container having epoxy coating. Conventional Busbar Trunking System is meant for 100A to 400A current for an operating voltage upto 415V.

Larsen & Toubro has also Medium Voltage Busbar Trunking System for 400A to 5000A current for a load of 3.6 kV to 24kV. The enclosure is made of GI, Stainless Steel or Aluminium and is epoxy coated. The Busbars are made of Copper or Aluminium having multiple bolted splice plate joints.

All types of L&T Busbar Trunking Systems are ISO approved for their quality and for fire safety.

Engineered for Performance and Safety

This busbar system is meticulously designed to handle high voltage and current with proven short circuit withstand and dielectric strength. Its touch-proof, insulated enclosure exceeds IEC and IS standards, with built-in overheating protection and fire resistance. The compact, rectangular casing uses epoxy or polyester film insulation to ensure safety and lasting performance in challenging environments.

Simple Integration and Reliable Operation

Installation is streamlined with modular lengths (3m/6m) that feature plug-in tap-off or bolted joint connections for flexibility. The dust-proof, corrosion-resistant construction suits tough industrial and commercial environments. Maintenance is minimal due to the fully enclosed, pre-fabricated, and smooth-finished design.

Flexible Power Distribution for Modern Needs

Supporting 100A to 5000A ratings and standard IP54/IP65 protection, the system adapts to evolving project requirements through easy expansion. Its silent operation, superior power factor (>0.95), and low transmission losses boost efficiency, making it an optimal solution for panel boards, trunking, and ceiling/wall mounting in modern facilities.

FAQs of Sandwich Busbar Straight Length (Feeder Type):

Q: How is the Sandwich Busbar Straight Length installed and what mounting options are available?

A: The busbar is designed for straightforward installation, offering modular straight lengths (3m or 6m) that connect via bolt or joint clamp systems. It supports ceiling, wall, or trunking mounting, allowing flexible integration into a variety of industrial or commercial power distribution setups.

Q: What makes this busbar system especially safe and reliable for industrial use?

A: Safety is assured by its fully enclosed, insulated design with touch-proof surfaces, dielectric strength above 3kV for 1 minute, robust short circuit withstand (up to 50kA), and fire resistance (tested to IEC 60332). Overheating is prevented with built-in thermal insulation, meeting IEC 61439/IS 8623 standards.

Q: When should I consider modular feeder busbars over traditional cable systems?

A: Modular busbar systems are ideal when your application requires high safety, quick installation, space savings, and future expandability. They outperform traditional cables by offering minimal transmission losses, silent operation, and easy upgrades for changing load demands.

Q: Where can these busbars be used and what environments are they suited for?

A: These busbars excel in industrial power distribution, commercial panel boards, and any setting requiring robust, insulated enclosures. With IP54/IP65 ratings, mechanical impact resistance (IK08/IK10), fire, and corrosion resistance, they thrive under harsh or high-demand conditions, indoors or covered outdoor spaces up to 2000m elevation.

Q: What processes are involved in system expansion or maintenance?

A: System expansion is straightforward due to the modular designnew lengths or feeders can be added using plug-in tap-off boxes or joint connections without extensive downtime. Maintenance is minimal, with only periodic inspections needed thanks to the dust-proof, self-contained casing.

Q: How does using this busbar system benefit efficiency and reliability?

A: The system delivers over 98% power transmission efficiency due to low loss conductors and superior insulation. Its silent, dust-proof operation and high resistance to mechanical and environmental stress reduce maintenance and operational interruptions, ensuring consistent and reliable power delivery.
