Conventional Busbar End-Feed Box

Name: Conventional Busbar End-Feed Box
Brand: Ganpati Electricals Pvt. Ltd.
Price: 3148-3523 INR
Availability: InStock

Price 3148-3523 INR/ Kilograms

Get a Price/Quote

MOQ : 500 Kilograms

Conventional Busbar End-Feed Box Specification

Humidity %
Up to 95% RH

IP Rating
IP42

Overheating Protection
Thermal Resistant Enclosure

Operating Temperature
-10C to +55C

Shape
Rectangular

Insulation Material
High-Grade Epoxy

Connector Type
Copper Busbar Terminals

Mounting Type
Surface/Wall Mounted

Surface Finish
Powder Coated

Efficiency
100% Conduction (No Loss)

Feature
Durable, Rust Resistant

Product Type
Conventional Busbar End-Feed Box

Application
Busbar Trunking System

Protection Level
Double Insulated

Frequency (MHz)
50-60 Hz

Rated Voltage
415 V AC

Energy Consumption
Passive (No Own Consumption)

Output Type
Terminal Output

Color
Grey

Dimension (L*W*H)
280 x 180 x 145 mm

Weight
2.5 kg

Phase
Three Phase

Input Voltage
415 V

Size
Standard (Customizable)

Connection Type
Screw Type Terminal

Material
Mild Steel (MS)

No Of Poles
3 or 4

Conventional Busbar End-Feed Box Trade Information

Minimum Order Quantity
500 Kilograms

Supply Ability
15000 Kilograms Per Month

Delivery Time
1 Months

About Conventional Busbar End-Feed Box

Ganpati Electricals Pvt. Ltd. is a business partner of Larsen & Toubro for Bus Bar Trunking System, which is used in hotels, data centers, hospitals, airports, industries, factories, apartments etc. Electrical busbar systems are a modular approach to electrical wiring.

Busbar Trunking System is a prefabricated electrical distribution system consisting of busbars in a protective enclosure, including straight lengths, fittings, devices and accessories. These are mainly of two types namely Air-Insulated Trunking Busbar System and Sandwich Trunking Busbar System.

Sandwich Busbar Trunking System is epoxy insulated and used for transferring 400A to 6300A current for up to a maximum of 1000V. Compaired to this Conventional Busbar Trunking System is air insulated and is used for 100-400A current for upto a maximum of 415V. Besides these two, there comes also air-insulated Medium Voltage Busbar Trunking System for 100A to 6300A current for up to a maximum load of 33 kV.

Busbar Trunking System of L&T comes in a metal enclosure and is quite compact in size. It requires no maintenance and can easily last for more than 20 years. Compared to normal cabling, it requires much less space and can be installed within a very short time.

Sandwich Busbar Trunking System has a high tolerance to heavy voltage drop. It has single bolted copper or alumium busbars meant for 400A to 6300A current for a load of maximum 1000V.

Compared to Sandwich Busbar Trunking System, Conventional Busbar Trunking System is air-insulated. It has multi-bolted copper busbars housed in a 1.6 mm thick GI container having epoxy coating. Conventional Busbar Trunking System is meant for 100A to 400A current for an operating voltage upto 415V.

Larsen & Toubro has also Medium Voltage Busbar Trunking System for 400A to 5000A current for a load of 3.6 kV to 24kV. The enclosure is made of GI, Stainless Steel or Aluminium and is epoxy coated. The Busbars are made of Copper or Aluminium having multiple bolted splice plate joints.

All types of L&T Busbar Trunking Systems are ISO approved for their quality and for fire safety.

Unmatched Safety and Compliance

Our End-Feed Box ensures top-tier safety with a short circuit withstand capacity of up to 50 kA for 1 second and compliance with IS 8623 and IEC 60439 standards. The double-insulated, thermal-resistant enclosure reduces risks and ensures long-term reliability even in high-demand applications.

Flexible Installation and Connectivity

This unit accommodates bottom or side cable entry, with screw-type terminals and copper busbar connectors for secure and adaptable installation. Its compact, rectangular design fits standard spaces, while customizable sizes make it suitable for diverse busbar configurations in India.

Durability and Longevity Guaranteed

Constructed with 1.6 mm mild steel and a powder-coated finish, the box resists rust and withstands harsh environments. Its high-grade epoxy insulation material maintains performance, ensuring a service life exceeding 20 years under normal operating conditions.

FAQs of Conventional Busbar End-Feed Box:

Q: How is the busbar end-feed box installed in a busbar trunking system?

A: The busbar end-feed box is designed for easy surface or wall mounting, using standard fasteners. Cable entry is flexible, allowing for either bottom or side entry, and the screw-type terminal connections simplify the wiring process.

Q: What are the benefits of using a double-insulated, thermal-resistant enclosure?

A: Double insulation enhances electrical safety, minimizing the risk of accidental contact or leakage. The thermal-resistant enclosure protects components from overheating, thus improving operational safety and prolonging service life.

Q: When should I choose a 3-pole versus a 4-pole end-feed box?

A: Select a 3-pole box for standard three-phase systems without a neutral connection. Opt for a 4-pole version when a neutral is required, ensuring compatibility with your specific power distribution needs.

Q: Where can the end-feed box be used, and what environments is it suitable for?

A: The box is ideal for industrial and commercial busbar trunking systems. Its powder-coated, IP42-rated enclosure resists humidity (up to 95% RH) and temperature fluctuations from -10C to +55C, making it suitable for demanding installation sites.

Q: What steps are involved in connecting cables to the end-feed box?

A: First, select the appropriate cable entry point (bottom or side). Strip the cables to the correct length and secure them to the screw-type terminals. Ensure all connections are tight, and confirm proper earthing to complete the setup safely.

Q: How does the product ensure operational efficiency and safety?

A: The end-feed box features high-conductivity copper or aluminium compatibility, ensuring no energy loss during conduction. Its UL94 V0 flammability rating, rust-resistant material, and compliance with international standards reinforce both safety and efficiency.
