Sandwich Busbar Edgewise Elbow

Name: Sandwich Busbar Edgewise Elbow
Brand: Ganpati Electricals Pvt. Ltd.
Price: 3148-3523 INR
Availability: InStock

Price 3148-3523 INR/ Kilograms

Get a Price/Quote

MOQ : 500 Kilograms

Sandwich Busbar Edgewise Elbow Specification

Shape
Elbow (Edgewise) - 90 Degree Angle

Efficiency
Up to 99%

Power Factor
>0.95

Humidity %
95% RH

Overheating Protection
YES

IP Rating
IP55

Insulation Material
Glass fibre reinforced epoxy

Connector Type
Busbar clamp

Mounting Type
Panel / Trunking mount

Operating Temperature
-25C to +105C

Feature
Compact, flame-retardant, low electromagnetic field, maintenance-free, short-circuit resistant

Surface Finish
Epoxy coated

Product Type
Sandwich Busbar Edgewise Elbow

Application
Electrical panels, switchgear busbar trunking systems

Protection Level
IP55

Frequency (MHz)
50-60 Hz

Rated Voltage
690 V

Energy Consumption
Low

Output Type
Electrical distribution

Color
Red/Black/Grey

Dimension (L*W*H)
Customized, typically 300mm x 120mm x 120mm

Weight
1.2 kg

Input Voltage
Up to 690 V

Phase
Three Phase

Size
Customized as per busbar system

Material
Copper/Aluminium with epoxy insulation

No Of Poles
3 or 4

Connection Type
Bolt-on

Maintenance
No periodic maintenance required

Mechanical Strength
High mechanical rigidity for reliable operation

Installation
Quick joint assembly system

Current Rating
Up to 4000A (Depending on system request)

Short Circuit Withstand
Rated to withstand up to 100kA for 1 sec

Conductor Standards
IEC 61439-1/2 compliance

Halogen Free
Yes

Fire Class
V0 flame resistance (UL94)

Creepage Distance
Adequate for high voltage safety

Sandwich Busbar Edgewise Elbow Trade Information

Minimum Order Quantity
500 Kilograms

Supply Ability
15000 Kilograms Per Month

Delivery Time
1 Months

About Sandwich Busbar Edgewise Elbow

Ganpati Electricals Pvt. Ltd. is a business partner of Larsen & Toubro for Bus Bar Trunking System, which is used in hotels, data centers, hospitals, airports, industries, factories, apartments etc. Electrical busbar systems are a modular approach to electrical wiring.

Busbar Trunking System is a prefabricated electrical distribution system consisting of busbars in a protective enclosure, including straight lengths, fittings, devices and accessories. These are mainly of two types namely Air-Insulated Trunking Busbar System and Sandwich Trunking Busbar System.

Sandwich Busbar Trunking System is epoxy insulated and used for transferring 400A to 6300A current for up to a maximum of 1000V. Compaired to this Conventional Busbar Trunking System is air insulated and is used for 100-400A current for upto a maximum of 415V. Besides these two, there comes also air-insulated Medium Voltage Busbar Trunking System for 100A to 6300A current for up to a maximum load of 33 kV.

Busbar Trunking System of L&T comes in a metal enclosure and is quite compact in size. It requires no maintenance and can easily last for more than 20 years. Compared to normal cabling, it requires much less space and can be installed within a very short time.

Sandwich Busbar Trunking System has a high tolerance to heavy voltage drop. It has single bolted copper or alumium busbars meant for 400A to 6300A current for a load of maximum 1000V.

Compared to Sandwich Busbar Trunking System, Conventional Busbar Trunking System is air-insulated. It has multi-bolted copper busbars housed in a 1.6 mm thick GI container having epoxy coating. Conventional Busbar Trunking System is meant for 100A to 400A current for an operating voltage upto 415V.

Larsen & Toubro has also Medium Voltage Busbar Trunking System for 400A to 5000A current for a load of 3.6 kV to 24kV. The enclosure is made of GI, Stainless Steel or Aluminium and is epoxy coated. The Busbars are made of Copper or Aluminium having multiple bolted splice plate joints.

All types of L&T Busbar Trunking Systems are ISO approved for their quality and for fire safety.

Engineered for Safety and Performance

Each edgewise elbow is built with flame-retardant, halogen-free epoxy insulation ensuring maximum operating safety. With a mechanical structure capable of enduring high stress and a fire-resistance class of V0 (UL94), performance is not compromised in demanding electrical applications. The product efficiently manages up to 4000A and up to 690 V operation, ensuring both safety and durability in electrical power distribution systems.

Effortless Installation and Customizable Fit

This elbow segment features an innovative, quick joint assembly with a bolt-on connection, simplifying installation and reducing on-site labor time. Its compact design fits seamlessly into a variety of panel or trunking mount systems, and the dimensions can be tailored to specific project needs, making it suitable for a wide range of electrical distribution infrastructures.

FAQs of Sandwich Busbar Edgewise Elbow:

Q: How is the Sandwich Busbar Edgewise Elbow installed in electrical systems?

A: The elbow uses a bolt-on quick joint assembly system. This approach enables fast, secure connection to existing busbar trunking, suitable for panel or trunking mounts. The process reduces installation time and does not require specialized tools.

Q: What benefits does the edgewise elbow offer in terms of maintenance and safety?

A: This component is maintenance-free, owing to its robust insulation, high mechanical rigidity, and flame-retardant properties (V0 class, UL94). It also includes overheating protection and is halogen free, ensuring safety under demanding operational conditions.

Q: When should a 3-pole or 4-pole elbow be chosen?

A: Select a 3-pole elbow for standard three-phase power distribution, or a 4-pole elbow when a neutral line is required, such as in systems where balanced load or safety grounding is essential.

Q: Where can this busbar elbow be used effectively?

A: This product is suitable for use in electrical panels, switchgear busbar trunking systems, and industrial or commercial power distribution systems demanding high reliability and space efficiency.

Q: What conductor standards does the product comply with?

A: It adheres to IEC 61439-1/2 compliance, guaranteeing international safety and performance standards for panelboard and power switchgear assemblies.

Q: How does the elbow ensure reliability during electrical faults?

A: It is rated to withstand a short circuit current of up to 100kA for 1 second. Its high mechanical strength and superior insulation prevent damage during faults, ensuring system integrity and operator safety.

Q: What unique usage features distinguish this product?

A: In addition to its low energy consumption and high efficiency (up to 99%), the epoxy-coated, compact design minimizes electromagnetic emissions, offering both functional advantage and environmental safety.
